Thermal |
Detector Type | Vanadium oxide uncooled focal plane detector |
Effective Pixels | 400 (H) × 300 (V) |
Pixel Pitch | 17 μm |
Spectral Range | 8 μm–14 μm |
Sensitivity (NETD) | ≤35 mK (@f/1.0) |
Field of View | 7.5 mm: H:53.5°; V: 39.5° 13 mm: H:30.4°; V: 22.5° 19 mm: H:20.3°; V: 15.3° 25 mm: H:15.5°; V: 11.6° 35 mm: H:11.1°; V: 8.3° |
Thermal Focus Control | Fixed-focal |
Close Focus Distance | 7.5 mm: 1.2 m (3.93 ft) 13 mm: 2.9 m (9.51 ft) 19 mm: 5.5 m (18.04 ft) 25 mm: 9 m (29.53 ft) 35 mm: 36 m (118.10 ft) |
Detection Distance① | 7.5 mm: Vehicle: 633 m (2,078.36 ft); Human: 206 m (675.47 ft) 13 mm: Vehicle: 1,176 m (3,859.81 ft); Human: 382 m (1,253.26ft) 19 mm: Vehicle: 1,719 m (5,641.26 ft); Human: 559 m (1,833.41 ft) 25 mm: Vehicle: 2,262 m (7,422.71 ft); Human: 735 m (2,411.38 ft) 35 mm: Vehicle: 3,167 m (10,391.80 ft); Human: 1,029 m (3,375.94 ft) |
Recognition Distance② | 7.5 mm: Vehicle: 155 m (509.79 ft); Human: 53 m (173.69 ft) 13 mm: Vehicle: 289 m (946.75 ft); Human: 98 m (321.51 ft) 19 mm: Vehicle: 422 m (1,383.71 ft); Human: 144 m (471.45 ft) 25 mm: Vehicle: 555 m (1,820.67 ft); Human: 189 m (620.07 ft) 35 mm: Vehicle: 777 m (2,548.93 ft); Human: 256 m (868.46 ft) |
Identification Distance③ | 7.5 mm: Vehicle: 78 m (257.32 ft); Human: 26 m (86.85 ft) 13 mm: Vehicle: 146 m (477.88 ft); Human: 49 m (160.76ft) 19 mm: Vehicle: 213 m (698.44 ft); Human: 72 m (235.72 ft) 25 mm: Vehicle: 280 m (919.00 ft); Human: 95 m (310.16 ft) 35 mm: Vehicle: 392 m (1,286.60 ft); Human: 132 m (433.06 ft) |
Note: ①Detection Distance: Detects objects, but cannot recognize their characteristics (objects must cover more than 3.6 pixels of the image). ②Recognition Distance: Classifies objects into general categories, such as human, vehicle (the object must cover more than 14 pixels of the image). ③Identification Distance: Classifies objects into specific categories based on their characteristics, such as engineering truck, car (the object must cover more than 28 pixels of the image). |
Digital Detail Enhancement (DDE) | Yes |
Digital Zoom | 19 levels |
Thermal AGC | Auto/Manual |
Thermal Noise Reduction | 2D NR/3D NR |
Image Flip | 180°; Mirror |
Color Palettes | 18 (white hot/black hot/fusion/rainbow/golden autumn/midday/iron red/amber/jade/sunset/icefire/painting/pomegranate/emerald /spring/summer/autumn/winter) |
Visible |
Image Sensor | 1/1.8" CMOS |
Max. Resolution | 2688 (H) × 1520 (V) |
Pixel | 4 MP |
Horizontal Definition | ≥1100 TVL |
Min. Illumination | Color: 0.01 lux
Black & white: 0.001 lux
0 lux (white light on) |
Visible AGC | Auto/Manual |
Visible Noise Reduction | 2D NR/3D NR |
S/N Ratio | >55 dB |
White Balance | Auto; manual; indoor; outdoor; tracking; sodium lamp;
street lamp; natural |
Defog | Electronic defog |
Electronic Shutter Speed | 1 s–1/30,000 s (auto/manual) |
BLC | Yes |
WDR | Yes |
HLC | Yes |
Day/Night | Auto (ICR); Color; B/W |
Iris Control | Fixed |
Image Flip | 180°; Mirror |
Exposure Compensation | Yes |
Visible Focus Control | Fixed-focal |
Field of View | 4 mm: H: 87.0°; V: 47.3° 6 mm: H: 55.3°; V: 30.0° 12 mm: H:37.3°; V: 21.4° 10–30 mm: H: 42°–15°;V: 23°–8.4° |
Close Focus Distance | 4 mm: 1.2 m (3.93 ft) 6 mm: 2.5 m (8.20 ft) 12 mm: 7.4 m (24.27 ft) 10–30 mm: 9 m (29.53 ft) |
Aperture | 4 mm: F1.6 6 mm: F1.6 12 mm: F1.7 10–30 mm: F1.7 |
Illuminator On/Off Control | Auto; manual |
Illumination Distance | 80 m (262.47 ft) |
Audio and Video |
Video Compression | H.265; H.264M; H.264H; H.264B |
Resolution | Thermal: Main stream: 1280 × 1024; 1280 × 960; 1280 × 720; 400 × 300; 1280 × 960 (default) Sub stream: 640 × 512; 640 × 480; 400 × 300; 400 × 300 (default) Visible: Main stream: 2688 × 1520; 2560 × 1440; 1920 × 1080; 1280 × 720); 704 × 576; 2560 × 1440 (default) Sub stream: 704 × 576; 352 × 288; 704 × 576 (default) |
Video Frame Rate | Thermal (50 Hz): Main stream: 1 fps–25 fps, 25 fps by default Sub stream: 1 fps–25 fps, 15 fps by default Visible (50 Hz): Main stream: 1 fps–25 fps, 25 fps by default Sub stream: 1 fps–25 fps, 15 fps by default Thermal (60 Hz): Main stream: 1 fps–30 fps, 30 fps by default Sub stream: 1 fps–30 fps, 15 fps by default Visible (60 Hz): Main stream: 1 fps–30 fps, 30 fps by default Sub stream: 1 fps–30 fps, 15 fps by default |
Audio Compression | G.711a; G.711 mu |
Image Encoding Format | JPEG |
Function |
Two-way Audio | Yes |
Sound and Light Alarm | Local audio and white light alarm prompts |
Network Protocol | IPv4/IPv6; HTTP; HTTPS; 802.1x; QoS; FTP; SMTP; UPnP; SNMP; DNS; DDNS; NTP; RTSP; RTP; TCP; UDP; IGMP; ICMP; DHCP; PPPoE |
Region of Interest (RoI) | Yes (customizable) |
Storage | FTP; Micro SD card (512 GB, hot swapping) |
Interoperability | ONVIF; CGI; DaHua SDK |
Browser | IE; Firefox; Chrome; Safari |
User/Host | Up to 20 (total bandwidth: 64 MB) |
Security | Authorized username and password; attached MAC
address; encrypted HTTPS; IEEE 802.1x; controlled
network access |
User Management | Up to 20 users; supports multi-level user permissions (2
levels): management group and user group |
Malfunction Detection | Network disconnection detection; IP conflict detection;
memory card state detection; memory space detection |
Fusion Mode | Yes. Off by default |
PIP | Yes |
Intelligence |
Heat Detection | Yes |
Cold/Hot Spot Trace | Yes |
Perimeter Protection | Yes. Supports tripwire and intrusion. |
Target Distinction | Human/Vehicle Classification |
Target Tracking | Yes |
Smoke Detection | Yes |
Port |
Analog Output | 1 × CVBS output; BNC port (not supported by the device with a junction box) |
Network Port | 1 × RJ-45 (10/100 Base-T) |
Alarm Input | 2 |
Alarm Output | 2 |
Audio Input | 1 |
Audio Output | 1 |
RS-485 | 1 |
Power |
Power Supply | 12 VDC ± 20%, PoE (802.3af), ePoE |
Power Consumption | Basic: 5 W (12 VDC); 8.9 W (PoE) Max: 15 W (12 VDC); 18 W (PoE) |
ePoE | Yes |
Environment |
Operating Temperature | –30 °C to +70 °C (–22 °F to +158 °F) |
Operating Humidity | ≤95% |
Storage Temperature | –40 °C to +70 °C (–40 °F to +158 °F) |
Physical Characteristics |
Protection | IP67 |
Reliability | Surge protection: 6 kV
Air discharge: 15 kV
Contact discharge: 8 kV |
Structure |
Product Dimensions | 300.9 mm × 181.8 mm × 181.8 mm (11.85" × 7.16" × 7.16") (L × W × H) |
Packaging Dimensions | 423 mm × 180 mm × 178 mm (16.65" × 7.09" × 7.01") (L × W × H) |
Net Weight | ≤2.35 kg (5.18 lb) |
Gross Weight | ≤2.7 kg (5.95 lb) |
Lens | Included |
Certification |
Certifications | CE/FCC |
Heat Detection Distance |
Certifications | Max. Distance |
7.5 mm | 45 m (147.64 ft) |
13 mm | 78 m (255.91 ft) |
19 mm | 114 m (374.02 ft) |
25 mm | 150 m (492.13 ft) |
35 mm | 210 m (688.98 ft) |
Note: The table displays the measured distances obtained from using the target size 0.2 m × 0.2 m for testing in an environment where the temperature is 23 °C and the relative humidity is below 60%. The table is for reference only. The distances within it are subject to actual conditions including atmospheric conditions, target size, the installation site, and more. |
Perimeter Protection Distance |
Certifications | Distance (Human) | Distance (Vehicle) |
7.5 mm | 60 m (196.85 ft) | 180 m (590.55 ft) |
13 mm | 104 m (341.21 ft) | 312 m (1,023.62 ft) |
19 mm | 152 m (498.69 ft) | 456 m (1,496.06 ft) |
25 mm | 200 m (656.17 ft) | 600 m (1,968.50 ft) |
35 mm | 280 m (918.64 ft) | 840 m (2,755.91 ft) |
Note: The table displays the measured distances obtained from using the target sizes 1.8 m × 0.5 m (human) and 1.4 m × 4 m (vehicle) for testing in an environment where the temperature is 23 °C and the relative humidity is below 60%. The table is for reference only. The distances within it are subject to actual conditions including atmospheric conditions, target size, the installation site, and more. |
